Diskbänk på konsoler FURO 904-02

Diskbänk på konsoler FURO 904-02

Flexibel diskbänk/arbetsbänk för exempelvis skola, butiker, sjukhus och livsmedelsindustri.
  • Idealisk för skola, förskola, livsmedelsbutik, livsmedels industri och sjukhus.
  • För sjukhusmiljöer med Vårdhygien klass 2, exempelvis vårdrum, sköljrum och desinfektionsrum. För Vårdhygien klass 3 se FURO 905.
  • Valfri längd mellan 500 och 3540 mm. Bredd 650 mm.
  • Bänkplan av 1,25 mm slipad rostfri plåt. Dubbel plåt används för ljuddämpande egenskaper.
  • Tillverkas helt i rostfritt stål i kvalitet EN 1.4301, helt utan organiska material. Se Variantutförande för bänkplan i syrafast rostfritt stål, EN 1.4404.
  • Stabil och slitstark konstruktion.
  • Många valmöjligheter med hjälp av alla tillbehör.
  • Bänk på konsoler ger en fri, lättstädad golvyta.
  • Sjukhus väljer, av hygieniska skäl, disklådor utan bräddavlopp. Vill man i skolmiljö eller storköksmiljö göra detsamma bör man kontrollera att golvbrunn finns i lokalen.

Build your bench

Variants

Build your countertop according to your measurements and preferences. Here, you can also equip your countertop with the accessories and additional details you want.



Number of brackets (mm/pcs):

Length: 500–1890 mm = 2
Length: 1900–3540 mm = 3


Placement of the Sink

Specify the desired sink placement using a c/c measurement from the right or left end panel.

  • For a single sink: the c/c measurement specifies the distance to the center of the sink.
  • For a double sink: the c/c measurement specifies the distance to the center of the total width of the double sink.


The sink is positioned 55 mm from the front edge of the countertop.

Narrow countertop

Narrow countertop

Countertop with an adjustable width between 600–645 mm.

Part no. 9VSB.

Sorting Hole, Metal Ring

Sorting Hole, Metal Ring

Sorting hole with removable metal ring.

  • Diameter: Ø215 mm

Part no. 988-05

Sorting Hole, Pressed

Sorting Hole, Pressed

Pressed hole for sorting or waste, easy to clean and especially suitable for food handling. Option to close with a lid for added functionality.

  • Diameter: Ø150 mm

Part no. 988-03

Sorting Hole, Counter-Sunk

Sorting Hole, Counter-Sunk

Counter-sunk hole for sorting or waste, easy to clean, especially suitable for food handling.

  • Diameter: Ø215 mm

Part no. 988-07

Acid-resistant countertop

Acid-resistant countertop

Countertop in acid-resistant stainless steel, grade EN 1.4404.

Part no. 9VSFBP

Wider countertop

Wider countertop

Countertop with a width of 700 mm.

Part no. 9VB700.

Standard edge profiles

P

Edge profile P

Standard som framkant och gavlar. Kan även väljas som bakkant.

T

Edge profile T

Standard som bakkant. Kan även väljas som gavlar.

Edge profile variants

Edge profile G

Kan väljas som framkant, gavlar och bakkant.

Edge profile V

Kan väljas som bakkant och gavlar.

Edge profile I

Kan väljas som bakkant och gavlar, endast i kombination med urtag, se Variantutföranden.

Täckning av kanter

Kantprofilerna T och I täcks i framkant om de väljs som gavel. Kantprofil V täcks alltid.

Sink BE-50

Stainless steel grade EN 1.4301. With overflow and strainer.

Part no. 9BE501

Sink BE-50

With overflow. Acid resistant quality EN 1.4404.

Part no. 9BE502

Sink BE-50

Without overflow. Acid resistant quality EN 1.4404.

Part no. 9BE50UB2

Sink BE-55

With overflow. Acid resistant quality EN 1.4404.

Part no. 9BE551

Sink BE-55

With overflow. Acid resistant quality EN 1.4404.

Part no. 9BE552

Sink BE-55

Without overflow. Acid resistant quality EN 1.4404.

Part no. 9BE55UB2

Sink BE-70

Stainless steel grade EN 1.4301. With overflow and strainer.

Part no. 9BE701

Sink RLE-34

Basket waste included. Stainless steel grade EN 1.4301.

Part no. 9RLE341

Sink RLE-34

Basket waste included. Without overflow. Acid resistant quality EN 1.4404.





Part no. 9RLEL34UBK2

Sink Round Ø350

Sink with rinsing function, suitable for laboratory environments. Hygienic design without overflow. Delivered with a welded drain spout and hygienic strainer.

For more information:
Installation instructions for Flushing Rim

Part no. 9RS352

Sink BE-SPECIAL

Manufactured with custom dimensions. Maximum dimensions: 1600x500x480 mm [LxWxD] Minimum dimensions: 250x250x50 mm [LxWxD] Stainless steel grade EN 1.4301.

Part no. 9BESPEC1

Sink BE-SPECIAL

Manufactured with custom dimensions. Maximum dimensions: 1600x500x480 mm [LxWxD] Minimum dimensions: 250x250x50 mm [LxWxD] Acid resistant quality EN 1.4404.

Part no. 9BESPEC2

Sink BE-SPECIAL without overflow

Manufactured with custom dimensions. Maximum dimensions: 1600x500x480 mm [LxWxD] Minimum dimensions: 250x250x50 mm [LxWxD] Without overflow. Stainless steel grade EN 1.4301.

Part no. 9BESPECUB1

Sink BE-SPECIAL

Manufactured with custom dimensions. Maximum dimensions: 1600x500x480 mm [LxWxD] Minimum dimensions: 250x250x50 mm [LxWxD] Without overflow. Acid resistant quality EN 1.4404.

Part no. 9BESPECUB2

Sink BE-SPECIAL

Stainless steel grade EN 1.4301. With overflow and strainer. Size 700x500x240 mm.

Part no. 9BE7050241

Sink BE-SPECIAL

Stainless steel grade EN 1.4301. With overflow and strainer. Size 700x500x360 mm.

Part no. 9BE7050361

Sinks BD-50 (double)

Stainless steel grade EN 1.4301. With overflow and strainer.

Part no. 9BD501

Sink BD-50 (double)

With overflow. Acid resistant quality EN 1.4404.

Part no. 9BD502

Sink BD-50 (double)

Without overflow. Acid resistant quality EN 1.4404.

Part no. 9BD50UB2

Sink BD-55 (double)

Stainless steel grade EN 1.4301. With overflow and strainer.

Part no. 9BD551

Sink BD-55 (double)

With overflow. Acid resistant quality EN 1.4404.

Part no. 9BD552

Sink BD-55

Without overflow. Acid resistant quality EN 1.4404.

Part no. 9BD55UB2

Sinks BD-70 (double)

Stainless steel grade EN 1.4301. With overflow and strainer.

Part no. 9BD701

Sink RLD-34 (double)

Basket waste included. Stainless steel grade EN 1.4301.

Part no. 9RLD341

Sink RLD-34

Basket waste included. Without overflow. Acid resistant quality EN 1.4404.

Part no. 9RLDL34UBK2

Shut-off valve

Shut-off valve

Chromed ball valve with handle, thread size R 1 1/2”.

Part no. 990

Gypsum separator

Gypsum separator

Volume: 13 l.
Dimensions: 360 x 370 x 430 mm.
Installation: The countertop must be mounted flush against the wall. The gypsum separator can be installed within the range of 200–405 mm from the wall (c/c measurement from the separator's inlet to the wall).
Front supports and any shelf/grate are excluded when installing the gypsum separator.

Part no. 9GA

Strainer bucket

Strainer bucket

Strainer bucket with a liftable strainer basket placed in the wash basin. Can only be used in combination with BE, BD, and K wash basins.

  • Volume: 1.6 liters.

Part no. 9SH

Extra bracket

Extra bracket

Extra bracket for handling heavy loads on the entire countertop or parts of it.

Part no. 9EK

Under-shelf, grate model

Under-shelf, grate model

Under-shelf in stainless steel, grate. Removable in sections for easy access and cleaning.

  • Depth: 400 mm.

Part no. 991-02

Trap

Trap

Plastic water trap.

Part no. 9VLD1, för dubbellåda

Under shelf

Under shelf

Stainless steel under shelf with a raised back edge and folded sides and front edge.

  • Depth: 450 mm.

Cabinet, Single Door

Cabinet, Single Door

Cabinet with a bottom shelf and one removable shelf, adjustable in five positions. The door has concealed, self-closing hinges with soft-close function for quiet closing.

  • Width: 400, 500, 600 mm
  • Height: 600 mm
  • Depth: 575 mm

Part no. 972-02H, högerhängd dörr

Part no. 972-02V, vänsterhängd dörr

Part no. 972EH400.

Cabinet, double doors

Cabinet, double doors

Cabinet with a base and one removable shelf, adjustable in five positions. Doors have concealed, self-closing hinges with soft-close function for quiet closing.

  • Width: 600, 800, 1000, 1200 mm
  • Height: 600 mm
  • Depth: 575 mm

Part no. 972-02DK

Part no. 972EH800.

Drawer unit, 3 drawers

Drawer unit, 3 drawers

Cabinet with three fully extendable drawers that slide on ball-bearing extension rails. Drawers with a width of 400 mm come with plastic containers, while others have metal inserts.

  • Width: 400, 500, 600 mm
  • Height: 600 mm
  • Depth: 575 mm

Drawer

Drawer

Fully extendable drawer with smooth sides, bottom, and back, sliding on ball-bearing extension rails. Drawers with a width of 400 mm come with plastic containers, while others include metal inserts.

  • Width: 400, 500, 600 mm
  • Height: 185 mm
  • Depth: 575 mm

Part no. 981-02

Splash Guard

Splash Guard

Splash guard for installation above the bench.

  • Height: 100–980 mm

Part no. 9SB1M1, med skruvhål

Part no. 9SB1M2, syrafast med skruvhål

Lock for Cabinet Door

Lock for Cabinet Door

Lock for base cabinet.

SH.png BVB.svg
